Bouveteuse

Description

Bouveteuse linéaire Marinus Powermax Enddmatcher 2022

Année: 2022

Voltage: 350/500 vac

The Powermax Endmatcher is designed for head-end machining (tongue and groove machine) of floorboards, decking and cladding using the through-feed method. This allows both fixed and variable lengths to be produced.

High capacity up to 24 boards per minute
Absolute squareness
Advanced Servo Drive & Control Technology by Lenze
Defecting, cutting to length and end matching
No blow-outs or splintering
Defect Crayon Mark Identification
CNC controlled milling carriage and saw blades
Driven belt conveyor for waste
User-Friendly control panel
Online remote support management
CE Safety and Electrical Standards – UL/CSA Standards

One of the unique and strong characteristics of the Endmatcher is its capacity. Depending on the product, the machine can achieve a capacity of up to 24 boards per minute.

The high speed milling motors in combination with profiling tools, which we have developed especially for this machine, result in a very high quality end result.

Wondering what capacity the Powermax Endmatcher can achieve in your production? We can calculate this for you based on information like: type of wood, board dimensions and your profile.

Description	Value
Lengths:	450 – 6000+ mm
Widths:	50 – 300 mm (up to 500 mm optional)
Thicknesses:	8 – 50 mm
Capacity:	Up to 24 pieces/min
Length modes:	Variable / Fixed / Optimizing round lengths

Weight:	3200 kg
Power:	32 kW
Air pressure:	6 bar
Dimensions (LxHxW):	2800 x 2000 x 1600 mm
Mill diameter:	125 mm
Saw blade diameter:	450 mm
Suction point diameter:	1x 200 mm / 2x 120 mm
Air speed extraction:	30 m/sec
