Perceuse inséreuse a goujons CNC Biesse Elix 1300

Perceuse inséreuse a goujons CNC Biesse Elix 1300 – Image 2

Perceuse inséreuse a goujons CNC Biesse Elix 1300 – Image 3

Perceuse inséreuse a goujons CNC Biesse Elix 1300 – Image 4

Perceuse inséreuse a goujons CNC Biesse Elix 1300

Imprimer

UGS : 2474 Catégorie : Perceuse Inséreuse à Goujons

Description

Description

Perceuse inséreuse a goujons CNC Biesse Elix 1300

Année 2015 , voltage 600V, 60 Cy, 3 Ph.

4 sections

Description:

BIESSE ELIX 1300 K3 CNC BORE, GLUE & DOWEL INSERTER

•	Drill Dowel Inserter – Features: A single-spindle for drilling, dowel insertion unit, and glue injecting unit installed on a carriage moving in the « X » axis. The position for drilling dowel insertion is provided through simple programs through the NC control or third party software.The Numerical Control interface is intuitive, user-friendly, and very easy to use.
•	Specifications: Max. parts length is 1,300 mm (51”); min. parts length is 120 mm (4.7”); parts thickness is 10 – 40 mm (0.4” to 1.5”).
•	Positioning Speed: « X » & « Y » axis positioning speed is 40 MPM (131 FPM), « Z » axis has manual adjustment with a max stroke of 40 mm (1.57″).The working units travel on precision machine ground ball screws powered by brushless AC Servo motors.
•	Work-Table: Working Zones … (4) with center fence position in up mode, (2) large work zones in down position, (4) hold-down cylinders.
•	Boring unit: The drilling unit is a high-speed unit with a 6,000 RPM spindle and max. drilling depth of 30 mm (1.25″); max. drill bit dia. is 12 mm (0.47″); manual adjustment of depth with digital indicator.
•	Dowel Insertion Unit: Dowel prepositioning ensuring high repeatability of inserting dowels for each hole; the distance between the dowel insertion unit and the drilling spindle is 32 mm (1.3″) for simultaneous drilling and dowel insertion when holes are spaced at 32 mm; Standard dowel dimensions, 8 x 30 mm, max. dowel projection 14 mm (0.551″).The glue tank holds up to 8 liters (3.1 gallons) of glue; the max. glue density is 900 CPS. The glue inserting unit has a flow sensor and electronic adjustment of the amount of glue.
•	Operator & Machine Control: Industrial Numerical Control with « PC » MS Windows-XP Pro. OS, 17” TFT-LCD screen; CD & HD 80 GB, USB port, Ethernet port for network connection, RS-232 serial port for Barcode Scanner, keyboard & mouse.Extremely simple Program Editor, macro & parametric programming. Icon driven, interactive Graphic Operator Interphase.
•	Complete With: Multi-Tap Transformer 600V – 50/60 Hz; Original Factory Machine Documentation.
