toupie shaper

Description

Shaper Griggio cnc T45 HSK

Modèle: T45 HSK

Avec entraineur.

The machine is equipped with:
– HSK 63E quick change shaft
– Motorized lifting and tilt with electronic digital displays
– Infeed displayed fence
– Aluminium fence plates
– Safety guard
– Guard for working on the spindle
– Inverter for rotation speed from 900-12000 rpm
– Reverse spindle switch
– No. 1 shaft with quick attachment HSK 63E
– Table with adjustable sector
– No. 2 suction dust hoods dia. 120 mm.
– Automatic start through inverter
– ‘CE’ standards

T45 SPINDLE MOULDER HSK63E PROGRAM4?CE”
* Electronic programmer with 4 axes TOUCH SCREEN
with colour graphic video 5,7? SIEMENS
* Automatic programming of fence positioning
in relation to the tool dia.
* Automatic vertical programming of the spindle
* Automatic tilt programming
* Adjustable sector programming
* Possibility to memorize up to 100 working programs
on 4 axes with 30 heights each progam
* Possibility to memorize no. 200 tools
* 2 speeds manual positioning of the axes with
quick memorizing key in the working program
* Automatic display of info and alarm messages
* Display of the spindle rotation speed
* Shaft sliding on re-circulating ball screw
* Adjustable hanging control panel board
* Support for the exclusion of the fence from the table
Technical data:
– Working table sizes 1200×750 mm.
– Working shaft:
* Tilting shaft -30°+45°
* Useful height with dia. -50 mm. 140 mm.
* Bottom stroke as regards the level of the table 85 mm.
* Top stroke as regards the level of the table 35 mm.
– Cup depth of the working table 140 mm.
– Max dimensions of the tool re-entering
under the working table 320×60 mm.
CONE:
* Connection dia. 48 mm.
* Height 32 mm.
* Locking strength 25.000 N
– Selfbraking motor power (10?) 7,5 hp (5,5 kw)
– Net weight 980 kg.
– Noise level according to CE ,3 db (A)
